la basse pression machine de moulage mécanique sous pression
>
Fully Automatic Brass Low Pressure Casting Machine 125KW

Fully Automatic Brass Low Pressure Casting Machine 125KW

Nom De Marque: DZ
Numéro De Modèle: RD-5040-S
Nombre De Pièces: 1 set
Prix: Négociable
Détails De L'emballage: bois
Conditions De Paiement: L / C, T / T, Western Union
Informations détaillées
Lieu d'origine:
Chine
Certification:
CE ISO
Inductances de fournaises:
3 * 35KW
Pression nominale hydraulique:
8MPA
Débit de gaz:
0,225m³ / h
Flux du système de refroidissement:
≥400L / min ≤600L / min
Température de liquide hydraulique:
≤55 ℃
Pression du système de refroidissement:
3-5BAR
Puissance totale:
125 kW
Max. Coup d'éjecteur:
48 mm
Capacité d'approvisionnement:
3 ensembles par mois
Mettre en évidence:

fully automatic brass casting machine

,

low pressure die casting machine 125KW

,

brass low pressure casting equipment

Description du produit

Brass Low Pressure Die Casting Machine: Smart Control, High Efficiency

Product Description:

Fully Automatic Brass Low Pressure Casting Machine 125KW 0

Fully Automatic Brass Low Pressure Casting Machine 125KW 1

Fully Automatic Brass Low Pressure Casting Machine 125KW 2

Features:

Precision Casting: Utilize low-pressure casting technology to accurately cast complex brass components in a controlled environment. This ensures a high degree of precision in the final product's shape and dimensions, reducing the need for subsequent machining.

Efficient Production: Brass low-pressure casting machines can complete a large number of casting tasks in a short period, increasing production efficiency. This is particularly important for industries requiring large-scale production.

Material Advantages: Brass, being a primary material for brass low-pressure casting, offers excellent electrical conductivity, thermal conductivity, and corrosion resistance. This makes brass an ideal choice for manufacturing products such as bathroom accessories, valves, water meters, and more.

Automated Processes: Equipped with intelligent control systems that can automate casting, pressure replenishment, and unloading processes, reducing manual intervention and improving production consistency and efficiency.

Environmental Performance:Use electric furnace control systems, which reduce energy consumption compared to other casting methods, making them more environmentally friendly.

Rapid Mold Change Capability: Allowing for quick mold replacements to accommodate different product requirements, enhancing production flexibility.

High-Density Castings: Automatic pressure replenishment functions, which help increase the density of castings, reducing the occurrence of cracks and pores.


Technical Parameters:

Properties Parameters
Equipment Size:L*W*H 5200*5000*3600mm
Total Weight 13T
Total power 125KW
Voltage 380V
Max. Die Dimensions 600*400*240mm
Max. Die Thickness 2*120mm
Max. Die Opening stroke 370mm
Max.Die Weight 200Kg
Max. force of die closing 2400KG
Max. force of ejector 500KW
Max. die ejector stroke 48mm
Furnace Melting rate 350KG/H
Furnace Capacity 1800KG
Furnace Inductors 3*35KW
Hydraulic Motor Power 8.7KW
Hydraulic Rated Pressure 8Mpa
Hydraulic fluid temperature ≤52℃
Cooling system Water PH value 7~8.5
Cooling system Pressure 3-5bar
Cooling system Temp. 20±2℃
Cooling system Flow ≥400L/Min ≤600L/Min
Air pressure Compressed air pressure 0.5-0.6Mpa
Air pressure Compressed air consumption 15m³/H

Applications:

Manufacturing Bathroom Accessories: Brass low-pressure casting machines are commonly used to manufacture bathroom accessories such as faucets, showerheads, faucet handles, and components for other sanitary equipment. The high corrosion resistance and decorative properties of brass make it an ideal material for bathroom products.

Water Meter Manufacturing: Brass low-pressure casting machines are used to produce the casings and internal components of water meters. Brass's excellent thermal conductivity and electrical conductivity make it an ideal material for water meters, aiding in accurate water measurement and recording.

Valve Manufacturing: Valves play a crucial role in industrial processes, and brass low-pressure casting machines are employed to manufacture high-quality valve components, ensuring their reliability and durability.

Automotive Components: In the automotive manufacturing industry, brass low-pressure casting machines can be used to produce various components such as engine parts, brake components, and transmission system parts.

Instruments and Gauges: Some high-precision instruments and gauges require brass parts to ensure their accuracy and stability.

Support and Services:

Technical Support and Service for Low Pressure Die Casting Machine

We provide technical support and service for low pressure die casting machine, including:

  • Troubleshooting for low pressure die casting machine
  • Preventive maintenance for low pressure die casting machine
  • Repair and replacement of low pressure die casting machine parts
  • Installation and commissioning of low pressure die casting machine
  • Training on how to operate low pressure die casting machine
  • Technical advice on low pressure die casting machine
  • Other services related to low pressure die casting machine


Company profile:

Xiamen Dingzhu Intelligent Equipment Co., Ltd. (est. 2016) is a global leader in intelligent manufacturing solutions specializing in low-pressure die casting, grinding, polishing, and automation systems. Our core offerings include automatic LPDC machines, robotic cell grinding/polishing systems, CNC polishing equipment, and turnkey production lines, serving industries such as water meter casting, door locks, auto parts, and precision deburring. With exports to 30+ countries (Turkey, India, Mexico, USA, Southeast Asia, etc.) and partnerships with top brands like Kohler and TOTO, we empower manufacturers with safer, greener, and smarter production through proprietary technologies like dynamic pressure control and multi-axis robotic algorithms. 50+ patents and a 60+ R&D team drive innovations in low-pressure casting and robotic automation. We deliver end-to-end solutions—from mold design (CAE simulation) to lean factory layouts—backed by 24/7 global support, localized service centers (India, Turkey, Egypt), and 48-hour on-site assistance. CE-certified with strict material inspection and a 1-year warranty, we prioritize eco-friendly practices and operational excellence. Committed to "liberating workers' hands," Dingzhu envisions leading the future of intelligent automation, helping clients achieve productivity breakthroughs and sustainable growth. Partner with us to transform your manufacturing with cutting-edge technology and world-class expertise.
Fully Automatic Brass Low Pressure Casting Machine 125KW 3
Fully Automatic Brass Low Pressure Casting Machine 125KW 4
Fully Automatic Brass Low Pressure Casting Machine 125KW 5

Packing and Shipping:

Packaging and Shipping of Low Pressure Die Casting Machine

The Low Pressure Die Casting Machine will be packed in a wooden box, which is reinforced with steel straps for extra protection. Packing materials used for the box include bubble wrap and polyethylene foam. Upon completion of packing, the box will be sealed with tape for further protection.

The Low Pressure Die Casting Machine will be shipped via air freight, sea freight, or land transportation, depending on customer’s needs and requirements. The shipping company and package will be carefully chosen to ensure safe and timely delivery of the product.

Fully Automatic Brass Low Pressure Casting Machine 125KW 6
Fully Automatic Brass Low Pressure Casting Machine 125KW 7
Fully Automatic Brass Low Pressure Casting Machine 125KW 8
Fully Automatic Brass Low Pressure Casting Machine 125KW 9
